It features a digital processing core that performs real -time video format conversion and image improvement. Format conversion is achieved through an innovative adaptive scaler that allows the device to upscale from any input format to 4K x 2K resolutions. Proprietary video processing algorithms improve the picture quality by removing unnaturally appearing noise or artifacts, smoothing edges and sharpening the image. Image improvement is su pported for both standard and high-definition video.



It contains the following video processing blocks:

 Input Preprocessing reformats the input signal to YCbCr 4:2:2 format

 Mosquito Noise Reduction

 Standard Definition Edge Smoothing

 High-definition Detail and Edge Enhancement

 Adaptive Video Scaling

 High-definition Edge Smoothing

 Test Pattern Generation

 Internal OSD Blending

 Output Postprocessing reformats the video data to many different output formats



It is preprogrammed with Highbandwidth Digital Content Protection (HDCP) keys for both receiver and transmitter, which helps reduce programming overhead and lowers manufacturing costs.



Video Input

 300 MHz HDMI receiver port with 3D support

 MHL with 1080p @ 60 Hz support

Video Output

 300 MHz HDMI transmitter port



Digital Audio Interface

 Inputs

 I2S input with multichannel support

 S/PDIF input

 Audio Return Channel (ARC) input

 Outputs

 I2S output with four data signals for multichannel formats, and flexible programmable channel mapping including DSD

 High Bitrate Audio output including Dolby¢çTrueHD and DTS-HD Master Audio¢â S/PDIF output supports LPCM, Dolby Digital DTS digital audio transmission with a 32 kHz – 192 kHz fS sample rateIntelligent audio mute capability avoids pops and noise with automatic soft mute and unmute IEC60958 or IEC61937 compatible.

* ÁÖÀÇ : º» Á¦Ç°Àº º°µµ·Î Àü¿øÀÌ µé¾î°¡´Â Á¦Ç°ÀÌ ¾Æ´Ï±â¿¡ Àå°Å¸® ¿¬°á½Ã¿¡´Â ½ÅÈ£°¡ °¨¼èµÇ¾î Ãâ·ÂÀÌ µÇÁö ¾ÊÀ» ¼ö Àֱ⿡, 2~3m ¾ÈÂÊÀ¸·Î¸¸ ¿¬°á ÇϽñ⠹ٶø´Ï´Ù.
